They come in circular and egg-shaped models in various sizes. Each type disc plug is only suitable for one size.
Product overview
| Ref. Lansas | Description | Max. pressure (bar) | Weight | Length (mm) | |
| B-101-010x | Disc Plug Circular Lansas Ø 100mm | 6 | 1 part | 50 | |
| B-101-012x | Disc Plug Circular Lansas Ø 125mm | 6 | 1 part | 50 | |
| B-101-015x | Disc Plug Circular Lansas Ø 150mm | 6 | 1 part | 50 | |
| B-101-016x | Disc Plug Circular Lansas Ø 160mm | 6 | 1 part | 50 | |
| B-101-018x | Disc Plug Circular Lansas Ø 180mm | 6 | 1 part | 50 | |
| B-101-020x | Disc Plug Circular Lansas Ø 200mm | 6 | 1 part | 60 | |
| B-101-023x | Disc Plug Circular Lansas Ø 230mm | 6 | 1 part | 60 | |
| B-101-025x | Disc Plug Circular Lansas Ø 250mm | 6 | 1 part | 60 | |
| B-101-028x | Disc Plug Circular Lansas Ø 280mm | 6 | 1 part | 60 | |
| B-101-030x | Disc Plug Circular Lansas Ø 300mm | 6 | 1 part | 60 | |
| B-101-532x | Disc Plug Circular Lansas Ø 300mm | 6 | 1 part | 100 | |
| B-101-533x | Disc Plug Circular Lansas Ø 330mm | 6 | 1 part | 100 | |
| B-101-035x | Disc Plug Circular Lansas Ø 350mm | 6 | 1 part | 60 | |
| B-101-038x | Disc Plug Circular Lansas Ø 380mm | 6 | 1 part | 60 | |
| B-101-038x | Disc Plug Circular Lansas Ø 380mm | 6 | 1 part | 100 | |
| B-101-040x | Disc Plug Circular Lansas Ø 400mm | 6 | 1 part | 60 | |
| B-101-040x | Disc Plug Circular Lansas Ø 400mm | 6 | 1 part | 100 | |
| B-101-043x | Disc Plug Circular Lansas Ø 430mm | 6 | 1 part | 60 | |
| B-101-045x | Disc Plug Circular Lansas Ø 450mm | 6 | 1 part | 60 | |
| B-101-045x | Disc Plug Circular Lansas Ø 450mm | 6 | 1 part | 100 | |
| B-101-048x | Disc Plug Circular Lansas Ø 480mm | 6 | 1 part | 60 | |
| B-101-548x | Disc Plug Circular Lansas Ø 480mm | 6 | 1 part | 100 | |
| B-101-050x | Disc Plug Circular Lansas Ø 500mm | 6 | 1 part | 60 | |
| B-101-550x | Disc Plug Circular Lansas Ø 500mm | 6 | 1 part | 100 | |
| B-101-055x | Disc Plug Circular Lansas Ø 550mm | 6 | 1 part | 60 | |
| B-101-058x | Disc Plug Circular Lansas Ø 580mm | 6 | 1 part | 60 | |
| B-101-060x | Disc Plug Circular Lansas Ø 600mm | 6 | 1 part | 60 | |
| B-101-060x | Disc Plug Circular Lansas Ø 600mm | 6 | 1 or 2 parts | 100 | |
| B-101-562x | Disc Plug Circular Lansas Ø 625mm | 6 | 1 or 2 parts | 100 | |
| B-101-065x | Disc Plug Circular Lansas Ø 650mm | 6 | 1 or 2 parts | 60 | |
| B-101-068x | Disc Plug Circular Lansas Ø 680mm | 6 | 1 or 2 parts | 60 | |
| B-101-570x | Disc Plug Circular Lansas Ø 700mm | 6 | 1 or 2 parts | 100 | |
| B-101-573x | Disc Plug Circular Lansas Ø 730mm | 6 | 1 or 2 parts | 100 | |
| B-101-575x | Disc Plug Circular Lansas Ø 750mm | 6 | 1 or 2 parts | 100 | |
| B-101-078x | Disc Plug Circular Lansas Ø 780mm | 6 | 1 or 2 parts | 60 | |
| B-101-580x | Disc Plug Circular Lansas Ø 800mm | 6 | 1 or 2 parts | 100 | |
| B-101-585x | Disc Plug Circular Lansas Ø 850mm | 6 | 1 or 2 parts | 100 | |
| B-101-088x | Disc Plug Circular Lansas Ø 880mm | 6 | 1 or 2 parts | 60 | |
| B-101-590x | Disc Plug Circular Lansas Ø 900mm | 6 | 1 or 2 parts | 100 | |
| B-101-595x | Disc Plug Circular Lansas Ø 950mm | 6 | 1 or 2 parts | 100 | |
| B-101-098x | Disc Plug Circular Lansas Ø 980mm | 6 | 1 or 2 parts | 60 | |
| B-101-100x | Disc Plug Circular Lansas Ø 1000mm | 6 | 1 or 2 parts | 100 | |
| B-101-105x | Disc Plug Circular Lansas Ø 1050mm | 6 | 1 or 2 parts | 100 | |
| B-101-110x | Disc Plug Circular Lansas Ø 1100mm | 6 | 1 or 2 parts | 100 | |
| B-101-112x | Disc Plug Circular Lansas Ø 1120mm | 6 | 1 or 2 parts | 100 | |
| B-101-115x | Disc Plug Circular Lansas Ø 1150mm | 6 | 1 or 2 parts | 100 | |
| B-101-118x | Disc Plug Circular Lansas Ø 1180mm | 6 | 1 or 2 parts | 100 | |
| B-101-120x | Disc Plug Circular Lansas Ø 1200mm | 6 | 1 or 2 parts | 100 | |
| B-101-125x | Disc Plug Circular Lansas Ø 1250mm | 6 | 1, 2 or 3 parts | 100 | |
| B-101-130x | Disc Plug Circular Lansas Ø 1300mm | 6 | 1, 2 or 3 parts | 100 | |
| B-101-138x | Disc Plug Circular Lansas Ø 1380mm | 6 | 1 or 2 parts | 100 | |
| B-101-140x | Disc Plug Circular Lansas Ø 1400mm | 6 | 1, 2 or 3 parts | 100 | |
| B-101-145x | Disc Plug Circular Lansas Ø 1450mm | 6 | 1 or 2 parts | 100 | |
| B-101-150x | Disc Plug Circular Lansas Ø 1500mm | 6 | 1, 2 or 3 parts | 100 | |
| B-101-160x | Disc Plug Circular Lansas Ø 1600mm | 6 | 1, 2 or 3 parts | 100 | |
| B-101-170x | Disc Plug Circular Lansas Ø 1700mm | 6 | 1, 2 or 3 parts | 100 | |
| B-101-175x | Disc Plug Circular Lansas Ø 1750mm | 6 | 1, 2 or 3 parts | 100 | |
| B-101-180x | Disc Plug Circular Lansas Ø 1800mm | 6 | 1, 2, 3 or 4 parts | 100 | |
| B-101-190x | Disc Plug Circular Lansas Ø 1900mm | 6 | 1, 2, 3 or 4 parts | 100 | |
| B-101-200x | Disc Plug Circular Lansas Ø 2000mm | 6 | 1, 2, 3 or 4 parts | 100 | |
| B-101-210x | Disc Plug Circular Lansas Ø 2100mm | 6 | 1, 2, 3 or 4 parts | 100 | |
| B-101-220x | Disc Plug Circular Lansas Ø 2200mm | 6 | 1, 2, 3 or 4 parts | 100 |
Technische specificaties
Disc Plug Circular Lansas Ø 100mm
B-101-010x
Disc Plug Circular Lansas suitable for pipe Ø 100mm
-
Article number
B-101-010x -
Min. diameter
100 -
Max. diameter
100 -
Length (mm)
50 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 125mm
B-101-012x
Disc Plug Circular Lansas suitable for pipe Ø 125mm
-
Article number
B-101-012x -
Min. diameter
125 -
Max. diameter
125 -
Length (mm)
50 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 150mm
B-101-015x
Disc Plug Circular Lansas suitable for pipe Ø 150mm
-
Article number
B-101-015x -
Min. diameter
150 -
Max. diameter
150 -
Length (mm)
50 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 160mm
B-101-016x
Disc Plug Circular Lansas suitable for pipe Ø 160mm
-
Article number
B-101-016x -
Min. diameter
160 -
Max. diameter
160 -
Length (mm)
50 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 180mm
B-101-018x
Disc Plug Circular Lansas suitable for pipe Ø 180mm
-
Article number
B-101-018x -
Min. diameter
180 -
Max. diameter
180 -
Length (mm)
50 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 200mm
B-101-020x
Disc Plug Circular Lansas suitable for pipe Ø 200mm
-
Article number
B-101-020x -
Min. diameter
200 -
Max. diameter
200 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 230mm
B-101-023x
Disc Plug Circular Lansas suitable for pipe Ø 230mm
-
Article number
B-101-023x -
Min. diameter
230 -
Max. diameter
230 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 250mm
B-101-025x
Disc Plug Circular Lansas suitable for pipe Ø 250mm
-
Article number
B-101-025x -
Min. diameter
250 -
Max. diameter
250 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 280mm
B-101-028x
Disc Plug Circular Lansas suitable for pipe Ø 280mm
-
Article number
B-101-028x -
Min. diameter
280 -
Max. diameter
280 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 300mm
B-101-030x
Disc Plug Circular Lansas suitable for pipe Ø 300mm
-
Article number
B-101-030x -
Min. diameter
300 -
Max. diameter
300 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 300mm
B-101-532x
Disc Plug Circular Lansas suitable for pipe Ø 300mm
-
Article number
B-101-532x -
Min. diameter
300 -
Max. diameter
300 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 330mm
B-101-533x
Disc Plug Circular Lansas suitable for pipe Ø 330mm
-
Article number
B-101-533x -
Min. diameter
330 -
Max. diameter
330 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 350mm
B-101-035x
Disc Plug Circular Lansas suitable for pipe Ø 350mm
-
Article number
B-101-035x -
Min. diameter
350 -
Max. diameter
350 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 380mm
B-101-038x
Disc Plug Circular Lansas suitable for pipe Ø 380mm
-
Article number
B-101-038x -
Min. diameter
380 -
Max. diameter
380 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 380mm
B-101-038x
Disc Plug Circular Lansas suitable for pipe Ø 380mm
-
Article number
B-101-038x -
Min. diameter
380 -
Max. diameter
380 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 400mm
B-101-040x
Disc Plug Circular Lansas suitable for pipe Ø 400mm
-
Article number
B-101-040x -
Min. diameter
400 -
Max. diameter
400 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 400mm
B-101-040x
Disc Plug Circular Lansas suitable for pipe Ø 400mm
-
Article number
B-101-040x -
Min. diameter
400 -
Max. diameter
400 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 430mm
B-101-043x
Disc Plug Circular Lansas suitable for pipe Ø 430mm
-
Article number
B-101-043x -
Min. diameter
430 -
Max. diameter
430 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 450mm
B-101-045x
Disc Plug Circular Lansas suitable for pipe Ø 450mm
-
Article number
B-101-045x -
Min. diameter
450 -
Max. diameter
450 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 450mm
B-101-045x
Disc Plug Circular Lansas suitable for pipe Ø 450mm
-
Article number
B-101-045x -
Min. diameter
450 -
Max. diameter
450 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 480mm
B-101-048x
Disc Plug Circular Lansas suitable for pipe Ø 480mm
-
Article number
B-101-048x -
Min. diameter
480 -
Max. diameter
480 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 480mm
B-101-548x
Disc Plug Circular Lansas suitable for pipe Ø 480mm
B-109-5481 Steel
B-109-5483 Rolled Alu
-
Article number
B-101-548x -
Min. diameter
480 -
Max. diameter
480 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 500mm
B-101-050x
Disc Plug Circular Lansas suitable for pipe Ø 500mm
B-109-0501 Steel
B-109-0502 Die-cast alu
B-109-0503 Rolled Alu
-
Article number
B-101-050x -
Min. diameter
500 -
Max. diameter
500 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 500mm
B-101-550x
Disc Plug Circular Lansas suitable for pipe Ø 500mm
-
Article number
B-101-550x -
Min. diameter
500 -
Max. diameter
500 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 550mm
B-101-055x
Disc Plug Circular Lansas suitable for pipe Ø 550mm
-
Article number
B-101-055x -
Min. diameter
550 -
Max. diameter
550 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 580mm
B-101-058x
Disc Plug Circular Lansas suitable for pipe Ø 580mm
-
Article number
B-101-058x -
Min. diameter
580 -
Max. diameter
580 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 600mm
B-101-060x
Disc Plug Circular Lansas suitable for pipe Ø 600mm
-
Article number
B-101-060x -
Min. diameter
600 -
Max. diameter
600 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 600mm
B-101-060x
Disc Plug Circular Lansas suitable for pipe Ø 600mm
-
Article number
B-101-060x -
Min. diameter
600 -
Max. diameter
600 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 625mm
B-101-562x
Disc Plug Circular Lansas suitable for pipe Ø 625mm
-
Article number
B-101-562x -
Min. diameter
625 -
Max. diameter
625 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 650mm
B-101-065x
Disc Plug Circular Lansas suitable for pipe Ø 650mm
-
Article number
B-101-065x -
Min. diameter
650 -
Max. diameter
650 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 680mm
B-101-068x
Disc Plug Circular Lansas suitable for pipe Ø 680mm
-
Article number
B-101-068x -
Min. diameter
680 -
Max. diameter
680 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 700mm
B-101-570x
Disc Plug Circular Lansas suitable for pipe Ø 700mm
-
Article number
B-101-570x -
Min. diameter
700 -
Max. diameter
700 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 730mm
B-101-573x
Disc Plug Circular Lansas suitable for pipe Ø 730mm
-
Article number
B-101-573x -
Min. diameter
730 -
Max. diameter
730 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 750mm
B-101-575x
Disc Plug Circular Lansas suitable for pipe Ø 750mm
-
Article number
B-101-575x -
Min. diameter
750 -
Max. diameter
750 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 780mm
B-101-078x
Disc Plug Circular Lansas suitable for pipe Ø 780mm
-
Article number
B-101-078x -
Min. diameter
780 -
Max. diameter
780 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 800mm
B-101-580x
Disc Plug Circular Lansas suitable for pipe Ø 800mm
-
Article number
B-101-580x -
Min. diameter
800 -
Max. diameter
800 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 850mm
B-101-585x
Disc Plug Circular Lansas suitable for pipe Ø 850mm
-
Article number
B-101-585x -
Min. diameter
850 -
Max. diameter
850 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 880mm
B-101-088x
Disc Plug Circular Lansas suitable for pipe Ø 880mm
-
Article number
B-101-088x -
Min. diameter
880 -
Max. diameter
880 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 900mm
B-101-590x
Disc Plug Circular Lansas suitable for pipe Ø 900mm
-
Article number
B-101-590x -
Min. diameter
900 -
Max. diameter
900 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 950mm
B-101-595x
Disc Plug Circular Lansas suitable for pipe Ø 950mm
-
Article number
B-101-595x -
Min. diameter
950 -
Max. diameter
950 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 980mm
B-101-098x
Disc Plug Circular Lansas suitable for pipe Ø 980mm
-
Article number
B-101-098x -
Min. diameter
980 -
Max. diameter
980 -
Length (mm)
60 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1000mm
B-101-100x
Disc Plug Circular Lansas suitable for pipe Ø 1000mm
-
Article number
B-101-100x -
Min. diameter
1000 -
Max. diameter
1000 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1050mm
B-101-105x
Disc Plug Circular Lansas suitable for pipe Ø 1050mm
-
Article number
B-101-105x -
Min. diameter
1050 -
Max. diameter
1050 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1100mm
B-101-110x
Disc Plug Circular Lansas suitable for pipe Ø 1100mm
-
Article number
B-101-110x -
Min. diameter
1100 -
Max. diameter
1100 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1120mm
B-101-112x
Disc Plug Circular Lansas suitable for pipe Ø 1120mm
-
Article number
B-101-112x -
Min. diameter
1120 -
Max. diameter
1120 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1150mm
B-101-115x
Disc Plug Circular Lansas suitable for pipe Ø 1150mm
-
Article number
B-101-115x -
Min. diameter
1150 -
Max. diameter
1150 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1180mm
B-101-118x
Disc Plug Circular Lansas suitable for pipe Ø 1180mm
-
Article number
B-101-118x -
Min. diameter
1180 -
Max. diameter
1180 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1200mm
B-101-120x
Disc Plug Circular Lansas suitable for pipe Ø 1200mm
-
Article number
B-101-120x -
Min. diameter
1200 -
Max. diameter
1200 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1250mm
B-101-125x
Disc Plug Circular Lansas suitable for pipe Ø 1250mm
-
Article number
B-101-125x -
Min. diameter
1250 -
Max. diameter
1250 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1300mm
B-101-130x
Disc Plug Circular Lansas suitable for pipe Ø 1300mm
-
Article number
B-101-130x -
Min. diameter
1300 -
Max. diameter
1300 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1380mm
B-101-138x
Disc Plug Circular Lansas suitable for pipe Ø 1380mm
-
Article number
B-101-138x -
Min. diameter
1380 -
Max. diameter
1380 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1400mm
B-101-140x
Disc Plug Circular Lansas suitable for pipe Ø 1400mm
-
Article number
B-101-140x -
Min. diameter
1400 -
Max. diameter
1400 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1450mm
B-101-145x
Disc Plug Circular Lansas suitable for pipe Ø 1450mm
-
Article number
B-101-145x -
Min. diameter
1450 -
Max. diameter
1450 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1500mm
B-101-150x
Disc Plug Circular Lansas suitable for pipe Ø 1500mm
-
Article number
B-101-150x -
Min. diameter
1500 -
Max. diameter
1500 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1600mm
B-101-160x
Disc Plug Circular Lansas suitable for pipe Ø 1600mm
-
Article number
B-101-160x -
Min. diameter
1600 -
Max. diameter
1600 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1700mm
B-101-170x
Disc Plug Circular Lansas suitable for pipe Ø 1700mm
-
Article number
B-101-170x -
Min. diameter
1700 -
Max. diameter
1700 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1750mm
B-101-175x
Disc Plug Circular Lansas suitable for pipe Ø 1750mm
-
Article number
B-101-175x -
Min. diameter
1750 -
Max. diameter
1750 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1800mm
B-101-180x
Disc Plug Circular Lansas suitable for pipe Ø 1800mm
-
Article number
B-101-180x -
Min. diameter
1800 -
Max. diameter
1800 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 1900mm
B-101-190x
Disc Plug Circular Lansas suitable for pipe Ø 1900mm
-
Article number
B-101-190x -
Min. diameter
1900 -
Max. diameter
1900 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 2000mm
B-101-200x
Disc Plug Circular Lansas suitable for pipe Ø 2000mm
-
Article number
B-101-200x -
Min. diameter
2000 -
Max. diameter
2000 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 2100mm
B-101-210x
Disc Plug Circular Lansas suitable for pipe Ø 2100mm
-
Article number
B-101-210x -
Min. diameter
2100 -
Max. diameter
2100 -
Length (mm)
100 -
Max. pressure (bar)
6
Technische specificaties
Disc Plug Circular Lansas Ø 2200mm
B-101-220x
Disc Plug Circular Lansas suitable for pipe Ø 2200mm
-
Article number
B-101-220x -
Min. diameter
2200 -
Max. diameter
2200 -
Length (mm)
100 -
Max. pressure (bar)
6
